| RFID | 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa | 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa | 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa |
| Mobile Card | NFC, BLE | NFC, BLE | NFC, BLE |
| Índice de protección | IP65, IP67 | IP65, IP67 | IP65, IP67 |
| Vandal Proof | IK08 | IK08 | IK08 |
| Usuarios (1:1) | 200,000 | 200,000 | 200,000 |
| Usuarios (1:N) | 200,000 | 200,000 | 200,000 |
| Eventos | 1,000,000 | 1,000,000 | 1,000,000 |
| Código (PIN) | No soportado | No soportado | No soportado |
| CPU | 1 GHz | 1 GHz | 1 GHz |
| Memoria | 4 GB Flash + 64 MB RAM | 4 GB Flash + 64 MB RAM | 4 GB Flash + 64 MB RAM |
| LCD Type | No soportado | No soportado | No soportado |
| LED | Multi color | Multi color | Multi color |
| Sonido | Buzzer (multi tono) | Buzzer (multi tono) | Buzzer (multi tono) |
| Temperatura de operación | -35°C ~ 65°C | -35°C ~ 65°C | -35°C ~ 65°C |
| Temperatura almacenamiento | -40°C ~ 70°C | -40°C ~ 70°C | -40°C ~ 70°C |
| Operación de humedad | 0% ~ 95%, no condensada | 0% ~ 95%, no condensada | 0% ~ 95%, no condensada |
| Humedad en almacenamiento | 0% ~ 95%, no condensada | 0% ~ 95%, no condensada | 0% ~ 95%, no condensada |
| Peso | Lector: 144g, Bracket: 30g (Including washer and bolt) | Lector: 220g, Bracket: 52g (Including washer and bolt) | Lector: 220g, Bracket: 52g (Including washer and bolt) |
| Dimensiones (WxHxD, mm) | 48 x 145 x 27 | 80 x 130 x 25 | 80 x 130 x 25 |
| Tamper | Soporta | Soporta | Soporta |
| Certificados | CE, FCC, KC, RoHS, REACH, WEEE, SIG | CE, FCC, KC, RoHS, REACH, WEEE, SIG | CE, FCC, KC, RoHS, REACH, WEEE, SIG |
| Wi-Fi | No soporta | No soporta | No soporta |
| RED (Ethernet) | 10/100 Mbps, auto MDI/MDI-X | 10/100 Mbps, auto MDI/MDI-X | 10/100 Mbps, auto MDI/MDI-X |
| RS-485 | Maestro o esclavo (Seleccionable) | Maestro o esclavo (Seleccionable) | Maestro o esclavo (Seleccionable) |
| Wiegand | Entrada o Salida (Seleccionable) | Entrada o Salida (Seleccionable) | Entrada o Salida (Seleccionable) |
| TTL (entradas) | 2 | 2 entradas | 2 entradas |
| Relay | 1 Relay | 1 Relay | 1 Relay |
| USB | No soporta | No soporta | No soporta |
| SD Card | No soporta | No soporta | No soporta |
| PoE | Soporta (IEEE 802.3af compliant) | Soporta (IEEE 802.3af compliant) | Soporta (IEEE 802.3af compliant) |
| Intercom | No soporta | No soporta | No soporta |
| Alimentación | DC 12 V / DC 24 V | DC 12 V / DC 24 V | DC 12 V / DC 24 V |
